Specifications and Features
Standard capacity: 1kg/500g per can
XY plane resolution: 0.047 mm
Recommended layer thickness/parameter: 10 sec @50µm
Recommended cleaning method: alcohol spray cleaning and air gun drying, such as soaking alcohol should not exceed 30 seconds
Application: Phrozen 3D Printer Series
Suitable for use: Proofing
Resin properties:
Viscosity: 742 cps
Specific gravity: 1.1
Tg：87 °C
Elongation: 130%
Fracture value: 19 MPa
Hardness: Shore 68 D
Impact strength: 23.79 KJ/m2
Precautions
Please use and store this resin at room temperature, in a dark and ventilated place.
Before using the resin, shake the resin evenly.
Recommended cleaning method: alcohol spray cleaning and air gun drying, such as soaking alcohol should not exceed 30 seconds
After use, please store the resin in an opaque bottle and avoid mixing with new materials.
Please keep this material out of reach of infants and young children and avoid direct sunlight.
Please wear gloves and a mask when operating. If skin or eyes come into contact with resin, wash immediately with plenty of water.
It is forbidden to dump this material arbitrarily. If you want to scrap it, please solidify the material and recycle the solid according to "general resources".
When unopened, it is recommended to store in a ventilated and cool place. The shelf life is 2 years. Please use it as soon as possible after opening.
Resources
SDS Substance Safety Data Sheet/Resin Instructions for Use (Download)
Resin parameters - Please select the resin parameters according to the printer you are using
